To readjust the angle, press 〈1〉.
✓
The user adjusts the angle using the angle stops visible through
the front access hatch (see Figure 3-3).
► Only use the fixed angle stop for fine angle changes (less
than 0.05°). Access the fixed angle stop through the side
access door. Remove the indicator. Handle the indicator
with care. DO NOT DROP OR BANG the indicator. Use
the provided Allen head wrench to turn the screw on the
back of the fixed angle stop.
NOTE
Do not turn the screw in the fixed angle stop more than
four times in either direction (the screw should not
extend more than 3/8" from the fixed angle stop).
Turn the screw clockwise to increase the angle or
counterclockwise to decrease the angle. At an angle of
1.25°, turn the screw one and a half turns to adjust the angle
about one hundredth of a degree.
► To make a large angle change (greater than 0.05°), use the
adjustable angle stop. First, remove the indicator. Handle
the indicator with care. DO NOT DROP OR BANG the
indicator. Loosen the two screws (about ¼ turn) with the
provided Allen wrench. Move the adjustable angle stop to
the desired angle (from 0.5° to 2.0°). Access the adjustable
angle screw by grasping the stop and turning the turntable
towards the access door. DO NOT rotate the turntable by
grasping the brake disk! Move the adjustable angle stop to
the desired angle (from 0.5° to 2.0°). The scale above the
stops provides a rough means of positioning the adjustable
angle stop.
WARNING
Removing the access doors exposes moving parts.
Remove all tools, except the indicator, from the
unit.
Step away from the unit while it calibrates the
angle.
