Truma Mover smart M RS1 - Adapter kit AL-KO M short up to 1800 kg; Adapter kit AL-KO M up to 1800 kg; Adapter kit AL-KO M 1900 kg - 2000 kg; Eriba Touring adapter kit

Mover smart M RS1Preparing for installation
24 EN
60040-00463 ∙ 00 ∙ 09/2023
Fig� 20
5.4.8 Adapter kit AL-KO M up to 1800kg
•
Suitable for caravans up to 1800 kg and an AL-KO M
chassis with adjustable beams�
•
Chassis is not set to minimum length�
•
For compensating overlapping frame edges�
•
Can only be installed in front of the axle�
•
Part No� 60030-38600
Fig� 21
5.4.9 Adapter kit AL-KO M 1900kg - 2000kg
•
Suitable for caravans up to 1900 kg - 2000 kg and
an AL-KO M chassis with adjustable beams�
•
For compensating overlapping frame edges�
•
Can only be installed in front of the axle�
•
Part No� 60031-02000
Fig� 22
5.4.10 Eriba Touring adapter kit
•
The Eriba Touring adapter kit is absolutely essential
for the EribaTouring chassis�
•
Installation is on the rectangular profile of the Eriba
Touring chassis�
•
The tyre size must be at least 14"�
•
The adapter kit can be installed in front of or behind
the axle, depending on the installation situation�
•
Part No� 60030-09000
Fig� 23
Substructures may need to be relocated�
In some cases installation is not possible because of the
design of the sub-frame�
Fig� 24
5.4.11 EribaTouringTroll adapter kit
•
For the EribaTouringTroll chassis, the EribaTour-
ingTroll adapter kit is absolutely essential�
•
Can only be installed behind the axle�
•
Part No� 60031-03000
Fig� 25
Fig� 26
