TurboChef i3 Service Manual

A-2 APPENDIX - REPLACING OVEN COMPONENTS
Figure
Reference #
Item Description Item Part Number Hardware Description Hardware Part Number(s)
1 Door Assembly i3-9308 Screw, #8-32 x 3/8, PFH, 100 Deg, SS 102809 (qty 6)
2 Door Gasket i3-9309 None None
3 Door Handle i3-9253 Screw, 1/4-20 x .25 lg, Serrated Hex 102947 (qty 4)
4 Door Skin i3-9109 Screw, 6-32 x .38, PFH, 100 Deg, SS 101430 (qty 9)
5 Drain Pan i3-9252 None None
N/A EMI Filter* 100546 Screw, M5 x 8, PPHD, Sems, SS 101707 (qty 4)
N/A EMI Filter Bracket* i3-9389 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 4)
N/A EMI Filter Cover* i3-9390 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 4)
6 Filter, Air i3-9039 None None
7 Filter Bracket i3-9060
A) Screw, Sh Mtl #8 x 1/2, Serrated PHTRH
B) Plug, Knockout, 1/2”, Black
A) 101688 (qty 6)
B) 101191 (qty 1)
8 Hand Grip (qty 4) i5-9256 Screw, #8 X 1/2, Serrated, PHTRH, Black Oxide 101691 (qty 2) each
9 Jetplate, Bottom i3-9160 Screws and Mounting Clips, Fast Lead i5-3201
10 Jetplate, Top, Ceramic
†
i5-3204 None None
11 Jetplate, Top, Insert
†
i3-9427 None None
12 Jetplate, Top, Metal
†
i3-9425 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 10)
13 Lower Front Panel i3-9246 None None
14 Rack i3-9167 None None
15 Shunt Plate Assembly i3-9307 Screw, 6-32 x .38, PFH, 100 Deg, SS 101430 (qty 9)
16 Stirrer, Metal
†
i3-9428
A) Screw, #10-32 x 1/2, PPH, SS
B) Washer, Lock, #10 Ext Tooth, Cres
A) 101460 (qty 1)
B) 102260 (qty 1)
17 Stirrer, Mica
†
i5-9154
A) Screw, #10-32 x 1/2, PPH, SS
B) Washer, Lock, #10 Ext Tooth, Cres
A) 101460 (qty 1)
B) 102260 (qty 1)
18 Vent Catalyst Foil Pack RWD-9191 None None
19 Vent Tube Cover NGC-1392 Screw, #6 x 3/8, PPHD, Drill Point, Zinc 101684 (qty 2)
20
Weldment, Heat Chnl, Vent
Tube
NGC-1397 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 6)
No Cover Removal Required (Figures A-1, A-2)
CAUTION: Before removing/installing any component, make sure the oven has cooled and the
screen reads “Oven Off.”
Hardware listed is required for installing component to oven.
* Detail on page A-9.
†
The i3 utilizes two versions of the top jetplate. Ovens with serial numbers between 00001 and 01000 use
the ceramic top jetplate. All i3 ovens with serial number 01001 and greater use the metal top jetplate that
includes the glass jetplate insert.

TurboChef i3 Specifications

General

Model	i3
Cooking Chamber	Stainless Steel
Cavity Dimensions	14.5 x 16 x 10 inches
Power Requirements	208-240V, 30A
Control Type	Touchscreen
