V04.00 | 2021/05
107
Activating QuickConnect via Configuration Assembly
The Configuration Assembly is part of the Assembly Class of the device.
Configuring the Configuration Assembly in RSLogix.
Activate QuickConnect via byte 9, bit 0 = 1 in the Controller Tags.
Fig.68: Configuring QuickConnect in RSLogix
Activating Quick Connect via Class Instance Attribute
Activate Quick Connect via Class Instance Attribute as follows:
Class Instance Attribute Value
0xF5 0x01 0x0C 0: deactivated (default)
1: activated
