turck TBEN-S Series User Manual

V04.00 | 2021/05
173
9.2 Evaluating diagnostic data
The diagnostics of the TBEN-S devices are mapped into the process data [}44].
9.2.1 PROFINET diagnostics
TBEN-S1-8DIP – diagnostic data mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
n - - - - - - VERR V1
ch4-7
VERR V1
ch0-3
n + 1 - - - - - - - -
PROFINET error codes
Station diagnostics (slot 0) PROFINET diagnostics
Diagnostics Error code Channel
Undervoltage
V1 0x0002 0
V2 0x0002 1
I/O diagnostics (slot 1) PROFINET diagnostics
Diagnostics Connector/pin Error code Channel
Overcurrent supply group Overcurrent supply VAUX1 at channel 0…3
VERR V1 K 0-3 C0 0x0130 0
C1
C2
C3
Overcurrent supply group Overcurrent supply VAUX1 at channel 4…7
VERR V1 K 4-7 C4 0x0131 0
C5
C6
C7
