V04.00 | 2021/05
39
8 Parameterizing and Configuring
8.1 Parameters – overview
8.1.1 I/O channel parameters
Parameters – Digital Modules
Default values are shown in bold.
Parameter name Value Meaning Description
Dec. Hex.
DMOD Extended digital
function
0 0x00 disabled
Activates or deactivates the ex-
tended functions (input filter, im-
pulse stretch, counter or PWM
output function) for the respect-
ive digital channel [}13].
1 0x01 Input filter and pulse
stretch
DMOD_
CNT
Extended digital
function CNT
0 0x00 disabled
1 0x01 Input filter and pulse
stretch
4 0x04 Counter in Hz
DMOD_
PWM
Extended digital
function PWM
0 0x00 disabled
1 0x01 Input filter and pulse
stretch
2 0x02 PWM output
EN_DO Activate output Kx
0 0x00 Yes
Activates or deactivates the out-
put function of the digital chan-
nel.
1 0x01 No
IST Pulse stretching
input (*10 ms)
0…254 0x00…
0xFF
Defines the duration of the pulse
stretching for digital input edges
from 10 to 2550 ms in multiples
of 10 ms.
10 = pulse of 100 ms
0 = pulse stretching deactivated
SRO Manual reset after
overcurr. chx
0 0x00 No
Defines, if a manual reset is ne-
cessary after an overcurrent oc-
curred at the channel.
1 0x01 Yes
VAUX1/VAUX2 pin1 Cx
(Chy/z)
0 0x00 24 VDC
The 24 VDC sensor/actuator sup-
ply at pin 1 of the connector is
switched on.
1 0x01 switchable The 24 VDC sensor/actuator sup-
ply at pin1 of the connector is
switchable via the process data.
2 0x02 Off The 24 VDC sensor/actuator sup-
ply at pin 1 of the connector is
switched off.
