Parameterizing and Configuring
Configuring devices at Modbus TCP
92
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
TBEN-S2-4AO – parameter registers
Parameter description [}39]
Register
no.
Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Channel 0
0xB000 - - - ORM DRE DCH DDI OPM - FFB
0xB001 - - - - - - - - URA IRA
0xB002 SVAL MSB SVAL LSB
Channel 1
0xB003 - - - ORM DRE DCH DDI OPM - FFB
0xB004 - - - - - - - - URA IRA
0xB005 SVAL MSB SVAL LSB
Channel 2
0xB006 - - - ORM DRE DCH DDI OPM - FFB
0xB007 - - - - - - - - URA IRA
0xB008 SVAL MSB SVAL LSB
Channel 3
0xB009 - - - ORM DRE DCH DDI OPM - FFB
0xB00A - - - - - - - - URA IRA
0xB00B SVAL MSB SVAL LSB
8.6.5 Meaning of the register bits
Designation Meaning
In-/output data
AI Analog input
AO Analog output
C Connector
DI Digital input
DO Digital output
DX DXP channel
P Pin
Module status
ARGEE ARGEE program running in the device.
COM Device-internal communication disturbed
DiagWarn Diagnostics available at the device.
FCE The Force Mode is activated, which means, the actual output values
may no match the ones defined and sent by the field bus.
V
1
System power supply too low (< 18 VDC).
V
2
System power supply too low (< 18 VDC).
Channel diagnostics
CJE Cold junction error
ERR Overcurrent at the respective output
LLVU Lower limit value underrun
