14.10.1 Basic error at 25 °C
Operation mode RTD/resistance
Measurement range 2-wire 3-wire 4-wire
Pt100 -200 °C…850 °C ≤ 0.2 %
Pt 100 -200 °C…150 °C ≤ 0.2 % ≤ 0.3 % ≤ 0.2 %
Pt 200 -200 °C…850 °C ≤ 0.7 % ≤ 0.2 % ≤ 0.3 %
Pt 200 -200 °C…150 °C ≤ 0.2 %
Pt 500 -200 °C…850 °C ≤ 0.3 % ≤ 0.2 %
Pt 500 -200 °C…150 °C ≤ 0.7 % ≤ 0.3 % ≤ 0.2 %
Pt 1000 -200 °C…850 °C ≤ 0.2 %
Pt 1000 -200 °C…150 °C ≤ 0.7 % ≤ 0.2 % ≤ 0.3 %
Ni 100 -60 °C…250 °C ≤ 0.2 % ≤ 0.3 % ≤ 0.2 %
Ni 100 -60 °C…150 °C ≤ 0.7 % ≤ 0.3 % ≤ 0.2 %
Ni 1000 -60 °C…250 °C ≤ 0.7 % ≤ 0.3 % ≤ 0.2 %
Ni 1000 -60 °C…150 °C ≤ 0.7 % ≤ 0.2 % ≤ 0.2 %
0…100 Ω ≤ 0.2 % ≤ 0.3 % ≤ 0.2 %
0…400 Ω ≤ 0.2 %
0…2 kΩ ≤ 0.2 %
0…4 kΩ ≤ 0.2 %
Operation mode thermocouple
Measurement range
Type K -270…1370 °C ≤ 0.7 % Only valid for lower measure-
ment range
Type B 100…1820 °C ≤ 0.5 %
Type E -270…1000 °C ≤ 1 % Only valid for lower measure-
ment range
Type J -210…1200 °C ≤ 0.1 %
Type N -270…1300 °C ≤ 0.1 %
Type R -50…1768 °C ≤ 0.2 %
Type S -50…1768 °C ≤ 0.2 %
Type T -200…400 °C ≤ 0.7 % Only valid for lower measure-
ment range
Type C 0…2315 °C ≤ 0.2 %
Type G 0…2315 °C ≤ 1.6 % Only valid for lower measure-
ment range
