Technical Data
Technical data – TBEN-S2-4AI
234
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Technical data
Repeatability 0.015 %
Temperature coefficient < 100 ppm/°C of full scale
Measurement error total (FSR) < 0,75 %
Operation mode RTD/resistance
Temperature unit °Celsius, °Fahrenheit
Measurement range n Pt 100 -200 °C…850 °C, Pt 100 -200 °C…150 °C
n Pt 200 -200 °C…850 °C, Pt 200 -200 °C…150 °C
n Pt 500 -200 °C…850 °C, Pt 500 -200 °C…150 °C
n Pt 1000 -200 °C…850 °C, Pt 1000 -200 °C…150 °C
n Ni 100 -60 °C…250 °C, Ni 100 -60 °C…150 °C
n Ni 1000 -60 °C…250 °C, Ni 1000 -60 °C…150 °C
n 0…100 Ω, 0…400 Ω, 0…2 kΩ, 0…4 kΩ
Connection options 2-wire, 3-wire, 4-wire
Input filter Standard, smooth
Cycle time ≤ 400 ms
Basic error [}235]
Repeatability 0.015 %
Temperature coefficient < 100 ppm/°C of full scale
Measurement error total (FSR) [}236]
Operation mode thermocouple
Temperature unit °Celsius, °Fahrenheit
Measurement range n Type K -270…1370 °C
n Type B 100…1820 °C
n Type E -270…1000 °C
n Type J -210…1200 °C
n Type N -270…1300 °C
n Type R -50…1768 °C
n Type S -50…1768 °C
n Type T -200…400 °C
n Type C 0…2315 °C
n Type G 0…2315 °C
Input filter Standard, smooth
Cold junction compensation None, Pt100, Pt1000, channel 0
Cycle time ≤ 400 ms
Basic error [}235]
Repeatability 0.015 %
Temperature coefficient < 100 ppm/°C of full scale
Measurement error total (FSR) [}236]
General information
MTTF 145 years acc. to SN 29500 (Ed. 99) 20 °C
