Parameterizing and Configuring
Configuring the devices at EtherNet/IP
106
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
8.8 Configuring the devices at EtherNet/IP
8.8.1 Common EtherNet/IP features
Feature Description
QuickConnect < 500 ms
Device Level Ring (DLR) Yes
Number of TCP connections 3
Number of CIP connections 10
Input assembly instance 103
Output assembly instance 104
Configuration assembly Instance 106
8.8.2 EDS files and catalog files
The EDS and catalog files can be downloaded free of charge from www.turck.com.
8.8.3 QuickConnect (QC)
The devices support QuickConnect. QuickConnect enables a PLC to build up connections to
EtherNet/IP nodes in less than 500 ms after switching-on the power supply for the EtherNet/IP
network. The fast start-up is necessary for fast tool changing applications at robot arms for ex-
ample in the automobile industry.
The devices support QuickConnect. The function can only be guaranteed for the digital chan-
nels.
QuickConnect can be activated via the web server in RSLogix, via or via the Configuration As-
sembly or Class Instance Attribute.
NOTE
Activating QuickConnect also activated the automatic setting of all necessary port-
properties.
Port property Status
Autonegotiation disabled
Transmission speed 100BaseT
Duplex Full duplex
Topology linear
AutoMDIX disabled
Please read chapter "Connecting” [}27]. for more information about the correct Ethernet-
cabling in QC-applications.
