V04.00 | 2021/05
229
14.6 Technical data – TBEN-S1-4DIP-4DOP
The station offers four digital inputs for 3-wire PNP-sensors and for digital outputs for DC actu-
ators.
Technical data
Power supply
Operating current (from V1) < 150 mA
Sensor/actuator supply VAUX1 Supply connector C0…C3 from V1
short-circuit proof, 0.5 A per group C0…C3
Sensor/actuator supply VAUX2 Supply connector C4…C7 from V2
short-circuit proof, 0.5 A per group C4…C7
Potential isolation From V1 and V2 voltage group,
voltages up to 500 VDC
Digital inputs
Number of channels 4
Connection technology M8, 3-pin
Input type EN 61131-2 type 3, PNP
Type of input diagnostics Group diagnostics
Signal voltage low level < 5 V
Signal voltage high level > 11 V
Signal current low level < 1.5 mA
Signal current high level > 2 mA
Input resistance low level Min. 3.33 kΩ
Input resistance high level Max. 5.5 kΩ
Input delay 0.2 ms/3 ms
Input frequency 400 Hz
Potential isolation Galvanic isolation to P1/P2,
voltage proof up to 500 VDC
Digital outputs
Number of channels 4
Connection technology M8, 3-pin
Output type PNP
Type of output diagnostics Channel diagnostics
Output voltage 24 VDC from potential group
Output current per channel 2 A, short-circuit-proof
Load type EN 60947-5-1: DC-13
Load type (UL condition) Resistive, pilot duty
Short-circuit protection Yes
Potential isolation Galvanic isolation to P1/P2,
voltage proof up to 500 VDC
General information
MTTF 264 years acc. to SN 29500 (Ed. 99) 20 °C
