14.10 Technical data – TBEN-S2-4AI
The module provides four analog inputs, which can be configured as voltage, current, RTD or
thermo couple input.
Technical data
Power supply
Operating current V1: min. 100 mA, max. 240 mA
Sensor/actuator supply VAUX1 Supply connector C0…C3 from V1
-circuit proof, 1 A per group C0…C3
Potential isolation V1/V2/Ethernet Galvanic isolation from V1 and V2 voltage group,
voltages up to 500 VDC
Power loss of the device, typical Max. 5 W
Analog inputs
Number of channels 4
Operating Modes n Voltage
n Current
n RTD
n Resistance
n Thermocouple
Resolution 16 bit
Data format n Standard 16 bit/12 bit left justified
n NE43
n Extended range
Operation mode voltage
Input filter Standard, smooth, fast, off
Max. input voltage 11.85 V
Load resistance > 100 kΩ
Input signals Differential, differential without ground, single ended
Measurement range 0…10 V, -10…10 V, 2…10 V,
0…5 V, 1…5 V, -1…1 V, -500…500 mV,
-100…100 mV, -50…50 mV
Mains suppression Off, 50 Hz, 60 Hz
Cycle time ≤ 4 ms
Basic error at 25 °C < 0,1 %
Repeatability 0.015 %
Temperature coefficient < 100 ppm/°C of full scale
Measurement error total (FSR) < 0,75 %
Operation mode current
Input filter Standard, smooth, fast, off
Max. input current 23 mA
Burden resistance < 50 Ω
Input signals Differential, differential without ground, single ended
Measurement range 0…20 mA, 4…20 mA, -20…20 mA
Mains suppression Off, 50 Hz, 60 Hz
Cycle time ≤ 4 ms
Basic error < 0,1 %
