Technical Data
Technical data – TBEN-S1-8DOP
228
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
14.5 Technical data – TBEN-S1-8DOP
The module offers eight digital outputs for DC actuators.
Technical data
Power supply
Operating current (from V1) < 150 mA
Sensor/actuator supply VAUX2 Supply connector C0…C7 from V2
short-circuit proof, 0.5 A per group C0…C3,
C4…C7
Potential isolation From V1 and V2 voltage group,
voltages up to 500 VDC
Digital outputs
Number of channels 8
Connection technology M8, 3-pin
Output type PNP
Type of output diagnostics Channel diagnostics
Output voltage 24 VDC from potential group
Output current per channel HW rev. < 2: 0.5 A, short-circuit-proof
HW rev. < 2: 2 A, short-circuit-proof
Load type EN 60947-5-1: DC-13
Load type (UL condition) Resistive, pilot duty
Short-circuit protection Yes
Potential isolation Galvanic isolation to P1/P2,
voltage proof up to 500 VDC
General information
MTTF 283 years acc. to SN 29500 (Ed. 99) 20 °C
