turck TBEN-S Series User Manual

Connecting
Connecting the supply voltage
28
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
6.3.1 Supply concept
All TBEN-S1-modules are supplied via 2 separate voltages V1 and V2. The I/O-channels are sep-
arated into the different potential groups "detachable I/O" (supplied through V2) and "non-de-
tachable" I/O (supplied through V1).
V1 = supply of the module electronics and the respective slots
V2 = supply of the respective slots
Digital modules
V1
V2
V1
V2
Fig.30: Supply TBEN-S1-8DIP/ TBEN-S1-8DIP-D Fig.31: Supply TBEN-S1-4DXP
V1
V2
V1
V2
Fig.32: Power supply TBEN-S1-8DOP Fig.33: Power supply TTBEN-S1-4DIP-4DOP/
TBEN-S1-8DXP
V1
V2
V1
V2
Fig.34: Power supply TBEN-S2-8DIP Fig.35: Power supply TBEN-S2-8DXP
