14 Technical Data
14.1 General technical data
Technical data
Power supply
Supply voltage 24 VDC
Permisible range 18…30 VDC
Total current Max. 4 A per voltage group
V1 + V2 max. 5.5 A at 70 °C per module
Potential isolation Galvanic isolation of V1 and V2 voltage groups
Connectors
Ethernet 1 x M8 (IN),
1 x M8 (OUT)
Power supply M8, 4-pin
Digital in-/outputs M8, 4-pin
M12, 5-pin
Permissible torques
n Ethernet (M8)
n I/O channels/supply (M8)
n I/O channels (M12)
n Mounting (M4 screws)
0.4 Nm
0.6 Nm
0.8 Nm
1.3 Nm
Isolation voltages
V1 to V2 ≥ 500 V AC
V1/V2 to field bus ≥ 500 V AC
System data
Transmission rate 10 Mbps/100 Mbps
Protocol detection Automatic
Web server Integrated
Service interface Ethernet via P1 or P2
Modbus TCP
Address assignment Static IP, BOOTP, DHCP
Supported function codes FC1, FC2, FC3, FC4, FC5, FC6, FC15, FC16, FC23
Number of TCP connections 8
EtherNet/IP
Address assignment According to EtherNet/IP standard
Device Level Ring (DLR) Supported
Quick Connect (QC) < 500 ms
Number of TCP connections 3
Number of CIP connections 10
Input Assembly Instance 103
Output Assembly Instance 104
Configuration Assembly Instance 106
PROFINET
Address assignment DCP
