Technical Data
General technical data
224
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Technical data
MinCycle Time 1 ms
Fast Start-Up (FSU) < 500 ms
Diagnostics According to PROFINET Alarm Handling
Automatic address setting Supported
Media Redundancy Protocol (MRP) Supported
Standard/directive conformity
Vibration test According to EN 60068-2-6
Acceleration Up to 20 g
Shock test According to EN 60068-2-27
Drop and topple According to IEC 60068-2-31/IEC 60068-2-32
Electro magnetic compatibility According to EN 61131-2
Approvals and certificates CE, FCC
UL cond. cULus LISTED 21 W2, Encl.Type 1 IND.CONT.EQ.
General information
Dimensions (B × L × H) 32 × 144 × 32 mm
Weight max. 215 g
Operating temperature -40…+70 °C
Storage temperature -40…+85 °C
Operating height Max. 5000 m
Protection class IP65 IP67/IP69K (not evaluated by UL)
Housing material PA6-GF30
Housing color Black
Metal screw 303 stainless steel
Material label Polycarbonate
Halogen-free Yes
Mounting Via 2 mounting holes, Ø 4,6 mm
FCC declaration
NOTE
This device complies with the limits for a Class A digital device, according to Part 15
of the FCC Rules. Operation of this equipment in a residential area may cause harm-
ful interference. In this case, the user must correct the interference at his own ex-
pense.
