8.3 Process output data – overview
8.3.1 Process output data – digital modules
TBEN-S1-8DIP
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Control
0x0000 - - - - - - - - - - - - - - - -
Latch reset
0x0001 - - - - - - - - DI7 DI6 DI5 DI4 DI3 DI2 DI1 DI0
Counter reset
0x0002 - - - - - - - - - - - - - - - CNT_
Reset
TBEN-S1-8DIP-D
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Control
0x0000 - - - - - - - - - - - - - - - -
Latch reset
0x0001 - - - - - - - - DI7 DI6 DI5 DI4 DI3 DI2 DI1 DI0
Counter reset
0x0002 - - - - - - - - - - - - - - - CNT_
Reset
TBEN-S2-8DIP-D
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Control
0x0000 - - - - - - - - - - - - - - - -
Latch reset
0x0001 - - - - - - - - DI7 DI6 DI5 DI4 DI3 DI2 DI1 DI0
Counter reset
0x0002 - - - - - - - - - - - - - - - CNT_
Reset
