Parameterizing and Configuring
Process output data – overview
54
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
TBEN-S1-8DOP
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Control
0x0000 - - - - - - - - - - - - - - - -
Outputs
0x0001 - - - - - - - - DO7 DO6 DO5 DO4 DO3 DO2 DO1 DO0
PWM ch3
0x0002 - - - - - - - - Duty Cycle
PWM ch7
0x0003 - - - - - - - - Duty Cycle
TBEN-S1-4DIP-4DOP
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Control
0x0000 - - - - - - - - - - - - - - - -
Outputs
0x0001 - - - - - - - - - - - - DO7 DO6 DO5 DO4
Latch reset
0x0002 - - - - - - - - - - - - DI3 DI2 DI1 DI0
Counter reset
0x0003 - - - - - - - - - - - - - - - CNT_
Reset
PWM ch7
0x0004 - - - - - - - - Duty Cycle
TBEN-S1-4DXP
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Control
0x0000 - - - - - - - - - - - - - - - -
Outputs
0x0001 - - - - - - - - - - - - DX3 DX2 DX1 DX0
Latch reset
0x0002 - - - - - - - - - - - - DX3 DX2 DX1 DX0
Counter reset
0x0003 - - - - - - - - - - - - - - - CNT_
Reset
PWM Ch3
0x0004 - - - - - - - - Duty Cycle
