8.8.7 VSC – Vendor Specific Classes
In addition to supporting the above named CIP Standard Classes, the device support the
vendor specific classes described in the following.
Class code Name Description Applies to:
Dec. Hex.
100 0x64 Gateway Data and parameters for the
field bus specific part of the device.
all
102 0x66 Process data Process data
126 0x7E Miscellaneous
Parameters
Describes the EtherNet/IP™
port properties
131 0x83 Analog Input Parameters, diagnostics and data
for the analog inputs
TBEN-S2-4AI
132 0x84 Analog Output Parameters, diagnostics and data
for the analog outputs
TBEN-S2-4AO
148 0x94 Basic Data and parameters for the
basic functions of
the digital devices
TBEN-S1-8DIP
149 0x95 TBEN-S1-8DIP-D
150 0x96 TBEN-S1-8DOP
151 0x97 TBEN-S1-8DXP
152 0x98 TBEN-S1-4DIP-4DOP
156 0x9C Input Latch
Channel 0…3
In and output data for the
input latch function
n TBEN-S1-4DIP-4DOP
n TBEN-S1-4DXP
157 9x9D Ext. function
digital
Data and parameters for the
extended digital functions
(counter)
n TBEN-S1-8DIP
n TBEN-S1-8DIP-D
n TBEN-S1-8DXP
n TBEN-S1-4DIP-4DOP
n TBEN-S1-4DXP
n TBEN-S2-8DIP
n TBEN-S2-8DXP
158 0x9E Data and parameters for the
extended digital functions
n TBEN-S1-8DIP
n TBEN-S1-8DIP-D
n TBEN-S1-8DXP
n TBEN-S1-4DIP-4DOP
n TBEN-S1-4DXP
n TBEN-S2-8DIP
n TBEN-S2-8DXP
159 0x9F Data and parameters for the
extended digital functions
(PWM)
n TBEN-S1-8DOP
n TBEN-S1-4DIP-4DOP
160 0xA0 n TBEN-S1-4DXP
n TBEN-S1-8DXP
n TBEN-S2-8DXP
162 0xA2 Input Latch
Channel 0…7
In and output data for the
input latch function
n TBEN-S1-8DIP
n TBEN-S1-8DIP-D
n TBEN-S1-8DXP
n TBEN-S2-8DIP
n TBEN-S2-8DXP
165 0xA5 Basic Data and parameters for the
basic functions of
the digital devices
TBEN-S2-8DIP
168 0xA8 TBEN-S2-8DXP
