Designation Meaning
OFL Overflow
OVL Overload/overcurrent
RTDSC Overcurrent (RTD only)
UFL Underflow
ULVE Upper limit value exceeded
V1AOL Overcurrent VAUX1
WBR Wire break
Parameters
The chapter Parameterizing and Configuring [}39] contains a detailed parameter description.
Digital modules
DMOD Extended digital function
DMOD_CNT Extended digital function counter
DMOD_PWM Extended digital function PWM
EN_DO Activate output
IST Impulse stretch
SRO Manual reset after overcurrent
VAUX1 Pin1 Cx (Chy-z) Sensor/actuator supply VAUX1
Analog modules
TBEN-S2-4AI
CWT Current wiring type
DCH Deactivate channel
DDI Deactivate diagnostics
DRE Data representation
INFL Input averaging filter
IMR Current range
OPM Operation mode
RRA Resistance range
RTDT RTD type
RTDWT RTD wiring type
RWT Resistance wiring type
SUP Mains suppression
TCCCJ Thermocouple cold junction compensation
TCT Thermocouple type
TMU Temperature unit
UMR Voltage range
VWT Voltage wiring type
TBEN-S2-4AO
DCH Deactivate channel
DDI Deactivate diagnostics
DRE Data representation
FFB Output on fieldbus error
IRA Current range
OPM Operation mode
