Parameterizing and Configuring
Parameters – overview
40
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Parameters – TBEN-S2-4AI
Parameter name Value Meaning Description
Dec. Hex.
CWT Current wiring type
0 0x00 Differential
Differential input
1 0x01 Single ended Connection of sensors with common
ground [}33]
2 0x02 differential without
ground
Differential input
DCH Deactivate channel
0 0x00 No
Channel active
1 0x01 Yes Channel inactve
DDI Deactivate
diagnostics
0 0x00 No
Diagnostics active
1 0x01 Yes Diagnostics inactive
DRE Data representa-
tion
0 0x00 Standard
1 0x01 NE43
2 0x02 Extended range
INFIL Average value Cut-off frequency
(at -3 dB)
Cut-off frequency
(at -3 dB)
0 0x00 Standard
5 Hz 2 Hz
1 0x01 smooth 1 Hz 0.25 Hz
2 0x02 fast 30 Hz 15 Hz
3 0x03 Off 250 Hz 125 Hz
IMR Current range
0 0x00 4…20 mA
1 0x01 0…20 mA
2 0x02 20…20 mA
OPM Operation mode
0 0x00 Thermocouple
Selection of the operation mode for the
respective channel. If a channel is para-
meterized as voltage or current input,
the sensor supply is provided at pin 1
and 3. Thermocouples/RTDs/resistances
must not be connected if the channel is
set to this operation mode.
1 0x01 voltage
2 0x02 Current
3 0x03 Resistance
4 0x04 RTD
RRA Resistance range
0 0x00 0…100 Ohm
1 0x01 0…400 Ohm
2 0x02 0…2000 Ohm
3 0x03 0…4000 Ohm
RTDT RTD type
0 0x00 Pt100, -200…850 °C, -328…1562 °F
1 0x01 Pt100, -200…150 °C, -328…302 °F
2 0x02 Ni100, -60…250 °C, -76…482 °F
3 0x03 Ni100, -60…150 °C, -76…302 °F
4 0x04 Pt200, -200…850 °C, -328…1562 °F
5 0x05 Pt200, -200…150 °C, -328…302 °F
6 0x06 Pt500, -200…850 °C, -328…1562 °F
7 0x07 Pt500, -200…150 °C, -328…302 °F
8 0x08 Pt1000, -200…850 °C, -328…1562 °F
9 0x09 Pt1000, -200…150 °C, -328…302 °F
