turck TBEN-S Series User Manual

Operating
Evaluating diagnostic data
174
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
TBEN-S2-8DIP – diagnostic data mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
n - - - - VERR V1
C3
VERR V1
C2
VERR V1
C1
VERR V1
C0
n + 1 - - - - - - - -
PROFINET error codes
Station diagnostics (slot 0) PROFINET diagnostics
Diagnostics Error code Channel
Undervoltage
V1 0x0002 0
V2 0x0002 1
I/O diagnostics (slot 1) PROFINET diagnostics
Diagnostics Connector/pin Error code Channel
Overcurrent supply group Overcurrent supply VAUX1 at channel 0…3
VERR V1 C0 C0P1 0x01D0 0
VERR V1 C1 C1P1 0x01D1 0
VERR V1 C2 C2P1 0x01D2 0
VERR V1 C3 C3P1 0x01D3 0
TBEN-S1-8DIP-D – diagnostic data mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
n VERR V1
ch7
VERR V1
ch6
VERR V1
ch5
VERR V1
ch4
VERR V1
ch3
VERR V1
ch2
VERR V1
ch1
VERR V1
ch0
n + 1 - - - - - - - -
PROFINET error codes
Station diagnostics (slot 0) PROFINET diagnostics
Diagnostics Error code Channel
Undervoltage
V1 0x0002 0
V2 0x0002 1
I/O diagnostics (slot 1) PROFINET diagnostics
Diagnostics Connector/pin Error code Channel
Overcurrent supply group Overcurrent supply VAUX1 at channel x
VERR V1 ch0 C0 0x0100 0
VERR V1 ch1 C1 0x0101 0
VERR V1 ch2 C2 0x0102 0
VERR V1 ch3 C3 0x0103 0
VERR V1 ch4 C4 0x0104 0
VERR V1 ch5 C5 0x0105 0
VERR V1 ch6 C6 0x0106 0
VERR V1 ch7 C7 0x0107 0
