turck TBEN-S Series User Manual

V04.00 | 2021/05
175
TBEN-S1-8DOP – diagnostic data mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
n - - - - - - VERR V2
ch4-7
VERR V2
ch0-3
n + 1 ERR7 ERR6 ERR5 ERR4 ERR3 ERR2 ERR1 ERR0
PROFINET error codes
Station diagnostics (slot 0) PROFINET diagnostics
Diagnostics Error code Channel
Undervoltage
V1 0x0002 0
V2 0x0002 1
I/O diagnostics (slot 1) PROFINET diagnostics
Diagnostics Connector/pin Error code Channel
Overcurrent supply group Overcurrent supply VAUX2 at channel 0…3
VERR V2 ch0-3 C0 0x0140 0
C1
C2
C3
Overcurrent supply group Overcurrent supply VAUX2 at channel 4…7
VERR V2 ch4-7 C4 0x0141 0
C5
C6
C7
Overcurrent at output Overcurrent
ERR0 C0 0x0001 0
ERR1 C1 0x0001 1
ERR2 C2 0x0001 2
ERR3 C3 0x0001 3
ERR4 C4 0x0001 4
ERR5 C5 0x0001 5
ERR6 C6 0x0001 6
ERR7 C7 0x0001 7
