Operating
Evaluating diagnostic data
176
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
TBEN-S1-4DIP-4DOP – diagnostic data mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
n - - - - - - VERR V2
ch4-7
VERR V1
ch0-3
n + 1 - - - - ERR7 ERR6 ERR5 ERR4
PROFINET error codes
Station diagnostics (slot 0) PROFINET diagnostics
Diagnostics Error code Channel
Undervoltage
V1 0x0002 0
V2 0x0002 1
I/O-diagnostics (slot 1) PROFINET diagnostics
Diagnostics Connector/pin Error code Channel
Overcurrent supply group Overcurrent supply VAUX1 at channel 0…3
VERR V1 ch0-3 C0 0x0120 0
C1
C2
C3
Overcurrent supply group Overcurrent supply VAUX2 at channel 4…7
VERR V2 ch4-7 C4 0x0121 0
C5
C6
C7
Overcurrent at output Overcurrent
ERR4 C4 0x0001 4
ERR5 C5 0x0001 5
ERR6 C6 0x0001 6
ERR7 C7 0x0001 7
