V04.00 | 2021/05
177
TBEN-S1-4DXP – diagnostic data mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
n - - - - - - VERR V2
Ch2-3
VERR V1
K0-1
n + 1 - - - - ERR3 ERR2 ERR1 ERR0
PROFINET error codes
Station diagnostics (slot 0) PROFINET diagnostics
Diagnostics Error code Channel
Undervoltage
V1 0x0002 0
V2 0x0002 1
I/O-diagnostics (slot 1) PROFINET Diagnostics
Diagnostics Connector/pin Error code Channel
Overcurrent supply group Overcurrent supply VAUX1 at Channel 0…1
VERR V1 K0-1 C0 0x0120 0
C1
Overcurrent supply group Overcurrent supply VAUX2 at Channel 2…3
VERR V2 Ch2-3 C4 0x0161 0
C5
C6
C7
Overcurrent at output Overcurrent
ERR0 C0 0x0001 0
ERR1 C1 0x0001 1
ERR2 C2 0x0001 2
ERR3 C3 0x0001 3
