Parameterizing and Configuring
Configuring the devices at EtherNet/IP
148
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Attribute no. Designation Get/Set Type Meaning
Dec. Hex.
4 0x04 Diagnostics ch3 –
overcurrent VAUX1
G USINT 0: -
1: active
5 0x05 Diagnostics ch4 –
overcurrent VAUX1
G USINT 0: -
1: active
6 0x06 Diagnostics ch5 –
overcurrent VAUX1
G USINT 0: -
1: active
7 0x07 Diagnostics ch6 –
overcurrent VAUX1
G USINT 0: -
1: active
8 0x08 Diagnostics ch7 –
overcurrent VAUX1
G USINT 0: -
1: active
9 0x09 Input value ch0 G USINT 0: off
1: on
10 0x0A Input value ch1 G USINT 0: off
1: on
11 0x0B Input value ch2 G USINT 0: off
1: on
12 0x0C Input value ch3 G USINT 0: off
1: on
13 0x0D Input value ch4 G USINT 0: off
1: on
14 0x0E Input value ch5 G USINT 0: off
1: on
15 0x0F Input value ch6 G USINT 0: off
1: on
16 0x10 Input value ch7 G USINT 0: off
1: on
Class 150 (0x96) – Basic
This class data and parameters for the device’s basic functions.
Applies to:
n TBEN-S1-8DOP
Attribute no. Designation Get/
Set
Type Meaning
Dec. Hex.
Parameters
1 0x01 Manual reset after
overcurr. ch0
G/S USINT 0: no
1: yes
2 0x02 Manual reset after
overcurr. ch1
G/S USINT 0: no
1: yes
3 0x03 Manual reset after
overcurr. ch2
G/S USINT 0: no
1: yes
