TBEN-S2-8DXP – diagnostic data mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
n - - - - VERR V2
P1 ch6-7
VERR V2
P1 ch4-5
VERR V1
P1 ch2-3
VERR V1
P1 ch0-1
n + 1 ERR7 ERR6 ERR5 ERR4 ERR3 ERR2 ERR1 ERR0
PROFINET error codes
Station diagnostics (slot 0) PROFINET diagnostics
Diagnostics Error code Channel
Undervoltage
V1 0x0002 0
V2 0x0002 1
I/O diagnostics (slot 1) PROFINET diagnostics
Diagnostics Connector/pin Error code Channel
Overcurrent supply VAUX1, pin 1 Overcurrent VAUX1 Pin1 Cx (Chy/z)
VERR V1 P1 C0 Ch 0-1 C0P1 0x01D0 0
VERR V1 P1 C1 Ch 2-3 C1P1 0x01D1 0
Overcurrent supply VAUX2, pin 1 Overcurrent VAUX2 Pin1 Cx (Chy/z)
VERR V2 P1 C2 Ch 4-5 C2P1 0x0422 0
VERR V2 P1 C3 Ch 6-7 C3P1 0x0423
Short-circuit at output Overcurrent
ERR0 C0 0x0001 0
ERR1 C1 0x0001 1
ERR2 C2 0x0001 2
ERR3 C3 0x0001 3
ERR4 C4 0x0001 4
ERR5 C5 0x0001 5
ERR6 C6 0x0001 6
ERR7 C7 0x0001 7
