TBEN-S2-4AO – diagnostic data mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Channel
0
n - - - WBR - - WBR OVL
Channel
1
n + 1 - - - WBR - - WBR OVL
Channel
2
n + 2 - - - WBR - - WBR OVL
Channel
3
n + 3 - - - WBR - - WBR OVL
PROFINET error codes
Station diagnostics (slot 0) PROFINET diagnostics
Diagnostics Error code Channel
Undervoltage
V1 0x0002 0
V2 0x0002 1
I/O diagnostics (slot 1) PROFINET diagnostics
Diagnostics Connector/pin Error code Channel
Overload (OVL) C0…C3 0x0004 0…3
Wire break (WBR) 0x0006
