Thermocouple Fahrenheit
Lower limit value underrun Upper limit value exceeded
ON OFF ON OFF
Type K -270…1370 °F -458.86 °F -454 °F 2522.66°F 2498 °F
Type B 100...1820 °F 210.2 °F 212 °F 3340.76 °F 3308 °F
Type E -270…1000 °F -458.86 °F -454 °F 1850 °F 1832 °F
Type J -210...1200 °F -349.78 °F -34.6 °F 2213.6 °F 2192 °F
Type N -270…1300 °F -458.86 °F -454 °F 2395.4 °F 2372 °F
Type R -50...1768 °F -58.9 °F -58 °F 3246.224 °F 3214.4 °F
Type S -50…1768 °F -58.9 °F -58 °F 3246.224 °F 3214.4 °F
Type T -270...400 °F -458.86 °F -454 °F 759.2 °F 752 °F
Type C 0…2315 °F -30.2 °F 32 °F 4240.67 °F 4199 °F
Type G 0...2315 °F -30.2 °F 32 °F 4240.67 °F 4199 °F
Diagnostics:
n Wire break (WBR): no thermocouple connected, process data will be set to 0x8000.
n Cold junction error (CJE)
n Upper limit value exceeded (ULVE)
n Lower limit value underrun (LLVU)
