turck TBEN-S Series User Manual

Operating
Measurement value representation of analog modules
206
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Decimal hexadecimal
(two's complement)
1…5 V
Dec. value = 8191.75 (1/V) × U
out
(V)
32767 7FFF Nominal range 5.0000 V
32766 7FFE 4.9998 V
… … …
16384 4000 3.0001 V
… … …
1 0001 1.0001 V
0 0000 1 V
-1 FFFF 1 V
… … …
-16384 C000 1 V
… … …
-32767 8001 1 V
-32767 8000 1 V
Voltage – extended range
Decimal hexadecimal
(two's complement)
-10…10 V
Dec. value = 2764.8 (1/V) × U
out
(V)
32767 7FFF 11.851 V
32752 7FF0 11.846 V
32512 7F00 11.760 V
32511 7EFF 11.759 V
32496 7EF0 11.75 V
27664 6C10 10.0058 V
27649 6C01 10.0004 V
27648 6C00 Nominal range 10.000 V
16 0010 5.787 mV
1 0001 361.7 µV
0 0000 0 V
-1 FFFF -361.7 µV
-162 FFF0 -5.787 mV
-6912 E500 -2.5 V
-27648 9400 -10 V
-27649 93FF -10.004 V
-27664 93F0 -10.0058 V
-32512 8100 -11.759 V
-32513 80FF -11.760 V
-32752 80F0 -11.846 V
-32767 8000 -11.852 V
