Decimal hexadecimal
(two's complement)
2…10 V
Dec. value = 3456 (1/V) × U
out
(V)
32767 7FFF 11.4812 V
32752 7FF0 11.4769 V
32512 7F00 11.4074 V
32511 7EFF 11.4041 V
32496 7EF0 11.4028 V
27664 6C10 10.0046 V
27649 6C01 10.0003 V
27648 6C00 Nominal range 2.0046 V
16 0010 2.0003 V
1 0001 2.0000 V
0 0000 0 V
-1 FFFF 0 V
-162 FFF0 0 V
-6912 E500 0 V
-27648 9400 0 V
-27649 93FF 0 V
-27664 93F0 0 V
-32512 8100 0 V
-32513 80FF 0 V
-32752 80F0 0 V
-32767 8000 0 V
