turck TBEN-S Series User Manual

Operating
Measurement value representation of analog modules
216
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Current – NE43
Decimal hexadecimal
(two's complement)
0…20 mA
Dec. value = 1000 (1/mA) × I
out
(mA)
65535 FFFF 22.000 mA
22001 55F1 22.000 mA
22000 55F0 22.000 mA
21001 5209 21.001 mA
21000 5208 21.000 mA
20001 4E21 20.001 mA
20000 4E20 20.000 mA
8000 1F40 Nominal range 8.000 mA
4000 0FA0 4.000 mA
2 0002 0.002 mA
1 0001 0.001 mA
0 0000 0.000 mA
Decimal hexadecimal
(two's complement)
4…20 mA
Dec. value = 1000 (1/mA) × I
out
(mA)
65535 FFFF 22.000 mA
22000 > 55F0 22.000 mA
22000 55F0 22.000 mA
21001 5209 21.001 mA
21000 5208 21.000 mA
20001 4E21 20.001 mA
20000 4E20 Nominal range 20.000 mA
8000 1F40 8.000 mA
4000 0FA0 4.000 mA
> 3999 0F9F ≤ 3.999 mA
3800 0ED8 3.800 mA
3600 0E10 3.600 mA
3599 0E0F 3.599 mA
2000 07D0 2.000 mA
> 1999 07CF 1.999 mA
1 0001 0.000 mA
