turck TBEN-S Series User Manual

V04.00 | 2021/05
31
TBEN-S1-4DIP-4DOP
Inputs
3 1
4
v
1 = V
AUX1
3 = GND V1
4 = Signal In
C0…C3
4 BK ( )
3 BU GND
1 BN (+)
v
C0...C3
Outputs
3 1
4
v
1 = V
AUX2
3 = GND V2
4 = Signal Out
C4…C7
2-wire connection:
4 BK ( )
3 BU GND
1 BN (+)
v
C4...C7
3-wire connection:
4 BK ( )
3 BU GND
1 BN (+)
v
C4...C7
With 3-wire connection, the actuator is sup-
plied via pin 1 but is not switched.
TBEN-S1-8DXP
3 1
4
v
1 = V
AUX1
3 = GND V1
4 = Signal In/Out
C0…C3
4 BK ( )
3 BU GND
1 BN (+)
Sensor
or
Actuator
v
C0...C7
3 1
4
v
1 = V
AUX2
3 = GND V2
4 = Signal In/Out
C4…C7
