Parameterizing and Configuring
Process input data – overview
50
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Name Meaning
Diagnostics
VERR V1 Ch xy Overcurrent VAUX1 at the channel/channels
VERR V1 Cx Overcurrent VAUX1 at the connector
VERR V2 Ch xy Overcurrent VAUX2 at the channel/channels
ERRx Overcurrent at output
PWM Diagnostics
PWM OUT ERR DOx Overcurrent at the PWM output
Module status
COM Device-internal communication disturbed
DiagWarn Diagnostic message at the device
FCE Force Mode activated
V1 System power supply too low (< 18 VDC).
V2 V2 too low (< 18 VDC).
