Parameterizing and Configuring
Configuring devices at PROFINET
62
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Index Name Data type Access Comment
25…31 0x19…
0x1F
reserved - - -
32 0x20 Input list ARRAY of
BYTE
read List of all module input channels
33 0x21 Output list ARRAY of
BYTE
read List of all module output chan-
nels
34 0x22 Diag. list ARRAY of
BYTE
read List of all I/O-channel dia-
gnostics
35 0x23 Parameter list ARRAY of
BYTE
read List of all I/O-channel paramet-
ers
36…
28671
0x24…
0x6FFF
reserved - - -
28672 0x7000 Module
parameters
WORD read/
write
Activate field bus protocol
28673…
45039
0x7001
…
0xAFEF
reserved - - -
45040 0xAFF0 I&M0-functions read Identification & Maintaining
45041 0xAFF1 I&M0-functions STRING[54] read/
write
I&M Tag function and
location
45042 0xAFF2 I&M2-functions STRING[16] read/
write
I&M Installation Date
45043 0xAFF3 I&M3-functions STRING[54] read/
write
I&M Description Text
45044 0xAFF4 I&M4-functions STRING[54] read/
write
I&M Signature
45045…
45055
0xAFF5
…
0xAFFF
I&M5 to I&M15-
functions
- not supported
Acyclic I/O channel user data
Index Name Data Type Access Comment
Dec. Hex.
1 0x01 Module parameters specific read/
write
Parameters of the module
2 0x02 Module type ENUM UINT8 read Contains the module type
3 0x03 Module version UINT8 read Firmware version of I/O
channels
4 0x04 Module ID DWORD read Ident number of the I/O
5…9 0x05 …
0x09
reserved - - -
10 0x0A Slave Controller
Version
UINT8 array
[8]
read Version number of the
slave controller.
11…18 0x0B…
0x12
reserved - - -
19 0x13 Input data specific read Input data of the respective
I/O-channel
