turck TBEN-S Series User Manual

Parameterizing and Configuring
Configuring devices at Modbus TCP
90
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
TBEN-S2-4AI – input registers
Meaning of the process input data [}51]
Register
no.
Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
AI0
0x0000 MSB LSB
AI1
0x0001 MSB LSB
AI2
0x0002 MSB LSB
AI3
0x0003 MSB LSB
Diagnostics
Channel 1 Channel 0
0x0004 LLVU UFL OFL WBR V1
AOL
ULVE RTD
SC
CJE LLVU UFL OFL WBR V1
AOL
ULVE RTD
SC
CJE
Channel 3 Channel 2
0x0005 LLVU UFL OFL WBR V1
AOL
ULVE RTD
SC
CJE LLVU UFL OFL WBR V1
AOL
ULVE RTD
SC
CJE
Module status
0x0006 - FCE - - - COM V1 - - - - - - - ARGEE Diag
Warn
TBEN-S2-4AI – parameter registers
Parameter description [}39]
Register
no.
Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Channel 0
0xB000 INFIL DRE DCH DDI OPM - TMU SUP
0xB001 RTDWT RRA RWT CWT IMR VWT UMR
0xB002 TCT TCCCJ RTDT
Channel 1
0xB003 INFIL DRE DCH DDI OPM - TMU SUP
0xB004 RTDWT RRA RWT CWT IMR VWT UMR
0xB005 TCT TCCCJ RTDT
Channel 2
0xB006 INFIL DRE DCH DDI OPM - TMU SUP
0xB007 RTDWT RRA RWT CWT IMR VWT UMR
0xB008 TCT TCCCJ RTDT
Channel 3
0xB009 INFIL DRE DCH DDI OPM - TMU SUP
0xB00A RTDWT RRA RWT CWT IMR VWT UMR
0xB00B TCT TCCCJ RTDT
