Table 9.1. Fuse protected chains
Designation Current, A Protected chains
Relay and fuse box in cabin
F1 10 ‘Dymos’ transfer case 15 A
F2 15 Cabin socket
F3 10 Air conditioner compressor
F4 30 Power options relay box 30 A
F5 7.5 Brake signal switch, interior lighting lamps,
glove compartment lamp, luggage compartment lamp
F6 40 Heating and air conditioning system, tailgate,
and mirror heating switch
F7 10 Left fog light
F8 10 Right fog light
F9 20 Windshield wiper switch, windshield wiper,
driver’s switch box, rear-seat passenger switch box,
rear bodyshell heater
F10 20 Heating of glass tailgate, mirrors, light control module
F11 – Not installed
F12 20 Cigarette lighter, luggage compartment socket
F13 30 ‘Dymos’ transfer case 30 A
F14 10 Window lifters (driver door module)
F15 5 Cluster 34 A, reverse movement switch, speed sensor 1
A, alarm signal switch 2 A
F16 15 Airbag
F17 10 Multimedia system
F18 15 Differential lock
F19 10 Left high beam
F20 10 Right high beam
F21 7.5 Left low beam
F22 7.5 Right low beam
F23 5 Right parking lamp
F24 5 Left parking lamp
F25 60 Windshield heating
F26 10 Reserve
F27 10 Reserve
F28 30 Reserve
F29 25 Reserve
F30 20 Reserve
Relay and fuse box under the hood
F1 15 Horn
F2 – Not installed
F3 30 Electric fan 2
F4 25 ABS (ESP)
