Step 3: connecting the print head electronics Mounting the electronics circuit board 87
6.6.3. Step 3: connecting the print head electronics
The following parts are needed in this step.
Letter Description Qnty.
Black electronic cable with 3 tiny plugs on both sides 1
To connect the print head electronics, perform the following actions
1. Turn the machine on its side.
2. Plug in the BLUE/PURPLE plug in the connector called FAN PWM on
the circuit board.
3. Plug in the PT100 plug in the connector called TEMP1 on the circuit
board.
4. Plug in the Heated bed temp plug in the connector called TEMP3 on
the circuit board.
6.6.4. Step 4: connecting the limit switches
To connect the limit switches, perform the following actions.
5. Connect the plug of BLACK wired limit switch 1 to the connector
Z-end stop on the circuit board.
The BLACK wired limit switch 2 is situated at the TOP of the machine.
6. Connect the plug of RED wired limit switch 4 to the connector Y-end
stop on the circuit board.
The RED wired limit switch 4 is situated at the FRONT of the machine.
7. Connect the plug of BLUE wired limit switch to the connector X-end
stop on the circuit board.
This BLUE wired limit switch situated at the LEFT of the machine.
6.6.5. Step 5: connecting the motors
To connect the motors, perform the following actions:
1. Connect the plug of X motor to the connector called X motor on the
circuit board.
The X motor is mounted on the BACK plane inside the machine.
2. Connect the plug of Y motor to the connector called Y motor on the
circuit board.
The Y motor is mounted on the LEFT panel inside the machine.
3. Connect the plug of Z motor to the connector called Z motor on the
circuit board.
The Z motor is mounted on BOTTOM panel under the machine.
4. Connect the plug of EXTRUDER-MOTOR to the connector called
EXTRUDER-MOTOR on the circuit board.
The EXTRUDER-MOTOR is mounted on the EXTRUDER outside the
machine
