Step 4: Mounting the axes Assembling the X/Y axes36
image 36: attaching the wooden caps in corner D
6.2.4. Step 4: Mounting the axes
The following parts are needed in this step.
Letter Description Qnty.
FRONT, LEFT, RIGHT, BACK slider blocks 4
A
timing belts 4
B
axes SHORT 2
C
axes LONG 2
D
timing pulleys 10
4 x
2 x
2 x
10 x
image 37: parts needed for this step
A
B
C
D
