Step 4: nishing the Z stage assembly Assembling the Z stage64
image 78: parts needed for this step
6.4.4. Step 4: nishing the Z stage assembly
The following parts are needed in this step.
Letter Description Qnty. Letter Description Qnty.
A
Main Wooden part
6mm
1
E
Wooden Right part 1
B
Wooden middel part
4mm
2
F
M3x14mm bolt 4
C
Wooden Left part 1
G
M3x12mm bolt 6
D
M3 Nut 10
