Ultimaker S5 User Manual

41
6.2 Material handling and storage
When you have multiple spools of material in use, or do not print with a material, it is very important that you store
them properly. If material is stored incorrectly, it may affect its quality and usability.
To keep your materials in optimal condition it is important that you keep them:
• Cool and dry
• Out of direct sunlight
• In a resealable bag
The optimal storage temperature for PLA, Tough PLA, Nylon, CPE, CPE+, PC, TPU 95A, PP and Breakaway is between
-20 to +30° C. For ABS the advised temperature is between 15 and 25° C and for PVA 0 to 30 °C. Furthermore a relative
humidity of below 50% is recommended for PVA, TPU 95A, PP and Breakaway. If these materials are exposed to a
higher humidity the quality of the material can be affected.
You can store the material in a resealable bag, including the supplied desiccant (silica gel). For PVA it is advised to store
the spool in a resealable bag with the supplied desiccant directly after printing to minimize moisture absorption.

Ultimaker S5 Specifications

General

Build Volume	330 x 240 x 300 mm
Layer Resolution	20 - 600 microns
Filament Diameter	2.85 mm
Max Nozzle Temperature	280 °C
Max Build Plate Temperature	140 °C
Print Technology	Fused Filament Fabrication (FFF)
Number of Print Heads	2
Build Plate	Heated glass build plate
Operating Sound	50 dBA
Print Speed	Up to 24 mm³/s
Display	4.7-inch color touchscreen
Operating Temperature	15 - 32 °C
Nozzle Diameter	0.25, 0.4, 0.6, 0.8 mm
Connectivity	Ethernet, Wi-Fi, USB
Supported Materials	PLA, ABS, Nylon, CPE, PVA, TPU 95A, PC, PP
Dimensions	495 x 585 x 780 mm
Feeder Type	Dual-geared
Print Head Movement Speed	300 mm/s
Build Plate Heating Time	Less than 4 minutes
Power Consumption	350 W
Travel Speed	300 mm/s
Operating Humidity	20 - 80% (non-condensing)
