Ultimaker S5 User Manual

1012134564 11
1 1 32 8 87 9
10
2.1 Main components Ultimaker S5
1. Glass doors
2. Print head
3. Build plate
4. Build plate clamps
5. Touchscreen
6. USB port
7. Feeder 2
8. Bowden tubes
9. Feeder 1
10. Power socket and switch
11. Ethernet port
12. Double spool holder with NFC cable
13. NFC socket

Ultimaker S5 Specifications

General

Build Volume	330 x 240 x 300 mm
Layer Resolution	20 - 600 microns
Filament Diameter	2.85 mm
Max Nozzle Temperature	280 °C
Max Build Plate Temperature	140 °C
Print Technology	Fused Filament Fabrication (FFF)
Number of Print Heads	2
Build Plate	Heated glass build plate
Operating Sound	50 dBA
Print Speed	Up to 24 mm³/s
Display	4.7-inch color touchscreen
Operating Temperature	15 - 32 °C
Nozzle Diameter	0.25, 0.4, 0.6, 0.8 mm
Connectivity	Ethernet, Wi-Fi, USB
Supported Materials	PLA, ABS, Nylon, CPE, PVA, TPU 95A, PC, PP
Dimensions	495 x 585 x 780 mm
Feeder Type	Dual-geared
Print Head Movement Speed	300 mm/s
Build Plate Heating Time	Less than 4 minutes
Power Consumption	350 W
Travel Speed	300 mm/s
Operating Humidity	20 - 80% (non-condensing)
