Inverter type
Model number
PMB100D PMB300D PMB600D PMB1200D PMB2400D
Voltage 200Vclass
Inverter type CIMR-VA2A0006
CIMR-VA2A0006 CIMR-VA2A0012 CIMR-VA2A0020
CIMR-VA2A0040
Voltage 400Vclass
Inverter type CIMR-VA4A0004
CIMR-VA4A0004 CIMR-VA4A0007 CIMR-VA4A0011
CIMR-VA4A0023
CAUTION
Control wiring for the inverter configuration and start-up (S1-SC),
please do not change so we are at the time of shipment. Please
However, if you activate the remote operation, under the control of
the input of non-voltage contact Remove the short-circuit line of
control wiring (S1-SC).
The multi-function analog input "A1", please do not connect the
wiring. It may cause malfunction.
Multi-function contact input terminal "S2", "S3", the setting of "S7"
is different from the inverter factory settings. The setting can not
be changed.
