WARNING
Failure to tighten bolts properly can lead to hazardous situations.
•
Ensure the tool is properly and securely bolted in place.
•
Ensure the tool is constructed such that it cannot create a hazardous situation
by dropping a part unexpectedly.
2.3.5. Control Box Clearance
The flow of hot air in the Control Box can result in equipment malfunction.
The Control Box requires a minimum clearance of 50mm on each side for sufficient cool airflow. The
recommended Control Box clearance is 200mm.
WARNING
A wet Control Box can cause fatal injury.
•
Make sure the Control Box and cables do not come into contact with liquids.
•
Place the Control Box (IP44) in an environment suited for the IP rating.
2.3.6. Maximum Payload
The rated payload of the Robot Arm depends on the center of gravity offset of the payload, see
Figure 2.3. Mechanical Interfaceon page30
The center of gravity offset is defined as the distance from the center of the tool flange to the center
of gravity of the attached payload.
When computing the payload mass in a pick and place application, for example, consider both the
gripper and object handled by the gripper.
Payload [kg]
