Technical data
13
3 Technical data
Type 100 Type 150 Type 200 Type 250
Dimensions
Length (without drawbar) [cm]
106 117
Length (with drawbar) [cm]
142 153
Width [cm]
78-93 79-100
Height [cm]
98 98 110 123
Weight fully equipped [kg]
128 141 144 147
Power supply [V~] 230/400
Power consumption max. [VA]
3000 3.000/6.000
Current consumption max. [A]
13/13
Protection class
I
Mixing volume max./min. [l] 100/15 150/30 200/30 250/30
Transport volume max. [l] depending on slope of covered distance (see figure 3/1)
Noise emission <72 dbA
Figure 3/1: Permitted transport volume
100 l
150 l
200 l
250 l
1 % 5 % 10 %
210 l
170 l
130 l
Slope
Transport
volume
85 l
