Start-up
24
5.5 Electrical connection
5.5.1 Requirements
The electrical connection must be
• secured by a separate fuse (16 A),
• protected by a residual current circuit breaker (Fl, 30 mA),
• and be wired as per IEC 60364-7-705. In case of an operating voltage of 400 V,
assure the clockwise phase sequence of your rotary field (see chapter 5.5.2,
page 25).
Depending on the heating used, the following electrical connections are required:
Electricity supply systems 230 V/400 V (EU)
Electricity supply systems 110 V/220 V (Canada, U.S., Japan)
DANGER
If the device is damaged whilst operating without a residual current circuit
breaker dangerous electrical voltage can be present at the housing. Operation
without a residual current circuit breaker is therefore not permitted.
CAUTION
Heater 2,500 W Heater 5,500 W
Operating voltage [V] 230, L/N/PE 400, L1/L2/L3/N/PE
Fuse min. [A] 16 3 x 16
Plug connector (EU) CEE 16 A (blue), 3-pin CEE 16 A (red), 5-pin
Plug connectors of other
countries
according to local standard according to local standard
Heater 2,500 W Heater 5,500 W
Operating voltage [V] 240 240
Fuse min. [A] 16 30
Plug connectors of other
countries
according to local standard according to local standard
