Programming and calibrating
46
version number, carry out the following steps:
1. Press the key for approx. 2 seconds.
2. Use to select the "Version number" function:
3. Press to switch to the display mode:
4. Press / to display the individual modules.
5. Press the key to exit the "Version numbers" menu.
To display the serial number, carry out the following steps:
1. Briefly press the key (approx. 1 second).
2. Use to select the "Serial number" function:
3. Press to switch to the display mode:
4. Press / to display the individual modules.
5. Press the key to exit the "Serial numbers" menu.
7.2 Calibration
Switch on the Milk Shuttle with the key
(approx. 2 seconds).
The "Calibrate" menu is accessed from the main menu:
Hold down the key for approx. 2 seconds.
This menu lets you adjust the pump and the temperature. The Milk Shuttle can be
calibrated either in mains or in battery mode.
After pressing the key, the LED of this key flashes. The last used calibration
menu is called up. Use the keys or to call up the menu "Calibrate pump" or
"Calibrate temperature" respectively.
7.2.1 Calibrate pump (time-controlled)
When calibrating the "SET pump" function, feed is conveyed for 5 seconds. The
conveyed amount is measured by the user and entered in the control.
-
Serial No. DIMA
BC4EC52E 06072273
-
16.07.14 10:30:32
MilkShuttle 105A31
