Start-up
25
5.5.2 Connecting to the power supply
To connect the device, you will need a connecting cable with the appropriate plug
connectors (CEE blue or red, not included).
1. Connect the plugs of the cable to the fixed socket outlet.
2. Lay the connecting cable so that it doesn't pose a stumbling hazard.
3. Connect the other end of the connecting cable to the outlet of the "Milk Shuttle"
(see figure 5/3).
4. Leave the device connected to the power supply for approx. 12 hours to charge
the internal batteries.
CAUTION
There may be no rolled-up cable reel in the supply lead.
Fire hazard!
CAUTION
ab
Figure 5/3: Electrical connection at the Milk Shuttle (examples)
a: CEE blue, 3-pin (230 V AC)
b: CEE red, 5-pin (400 V AC)
Information
Whilst the battery is charging, you can familiarize yourself with the device and do
the programming.
