Maintenance/Repairs
73
9.3
Replace batteries
9.3.1
Replace main batteries
Required tools:
Hexagon spanner 8 mm, hexa
gon spanner 10 mm
Allen key 6
mm
In order to replace batteries, carry o
ut the following steps:
1.
Unscrew the Allen screw
➊
and remove the protective
hood.
No.
Design
ation
Value
Fuse
d circuit
Configuration
1
F4
6.3 A
Agitator, glass fuse 230 V
5 x 20 mm
2
F1
10 A
Main fuse battery current 12 V
Blade-type fuse
Figure 9/7: Position of battery
1
2
3
72
74
