4.4.2 Agitator motor switch
4.4.3 Housing closures
The lid of the feed container and that of the control casing are equipped with self-
locking snap closures.
To open a snap closure, proceed as follows:
1. Press down safety lever
➊ .
2. Fold up closing lever
➋ .
3. Open closure completely
➌ .
Closing occurs in reverse order. Make sure the safety lever engages audibly.
II Agitate quickly (fast mode)
0 Agitator off
I Agitate slowly (slow mode)
Figure 4/4: Agitator master switch
Figure 4/5: Housing closure in detail
II
0
I
2
3
1
